High Pressure Low Lift Safety Valve
High Pressure Low Lift Safety Valve
- Availability: In Stock
- Product Model: A41Y
$0.00
Ex Tax: $0.00
High Pressure Low Lift Safety Valve
A41Y Type Low Lift Safety Valves are used for the equipment and pipeline of the air, N2, H2 Mixed gas, water and other medium with working temperature less than 200℃. Stainless Steel Trim Types are used for the equipment and pipeline of the quality with corrosive medium with working temperature less than 200℃.
Material List:
| NO. | Parts Name | Material (A41Y-160/A41Y-320) |
Material (A41Y-160P/A41Y-320P) |
Material (A41Y-160R/A41Y-320R) |
| 1 | Body | 35/40 | 1Cr18Ni9Ti | 1Cr18Ni12Mo2Ti |
| 2 | Nozzle | 2Cr13 | 1Cr18Ni9Ti | 1Cr18Ni12Mo2Ti |
| 4 | Disc | 2Cr13 | 1Cr18Ni9Ti | 1Cr18Ni12Mo2Ti |
| 5 | Guide Sleeve | 2Cr13 | 1Cr18Ni9Ti | 1Cr18Ni12Mo2Ti |
| 6 | Bonnet | ZG230-450 | 1Cr18Ni9Ti | 1Cr18Ni12Mo2Ti |
| 7 | Spring | 50CrVA | 50CrVA Coated PTFE | 50CrVA Coated PTFE |
| 8 | Stem | 2Cr13 | 1Cr18Ni12Mo2Ti | 1Cr18Ni12Mo2Ti |
| 9 | Adjusting Bolt | 45 | 2Cr13 | 2Cr13 |
| 10 | Cap | ZG200-400 | 1Cr18Ni9Ti | 1Cr18Ni9Ti |
