Cast Steel 150Lb Solid Wedge Gate Valve For Oil / Gas Size NPS 2"-48"

Cast Steel 150Lb Solid Wedge Gate Valve For Oil / Gas Size NPS 2"-48"
Cast Steel 150Lb Solid Wedge Gate Valve For Oil / Gas Size NPS 2"-48"
Cast Steel 150Lb Solid Wedge Gate Valve For Oil / Gas Size NPS 2"-48"
Cast Steel 150Lb Solid Wedge Gate Valve For Oil / Gas Size NPS 2"-48"
Cast Steel 150Lb Solid Wedge Gate Valve For Oil / Gas Size NPS 2"-48"
  • Availability: In Stock
  • Product Model: Z41Y
0 Write a review
$0.00
Ex Tax: $0.00
Add to Cart
Product Inquiry
Add to Wish List Compare this Product

Cast Steel 150Lb Solid Wedge Gate Valve For Oil & Gas Applications



Quick Details



Product Name Cast Steel 150Lb Solid Wedge Gate Valve
Valve Type Cast Steel 150Lb Solid Wedge Gate Valve
Size Range DN50~DN1000, 2"~40"
Pressure Range CLASS150~2500
Connection End RF, RTJ, BW
Standard API600, ASME B16.34, API 598, MSS SP-25
Operation Way Manual, Pneumatic Actuator, Electric Actuator
Packing Method Standard Sea worthy duly wooden boxs
Shipment Way By Express, By Air or BySea, as customer request





Construction is as follows:



- Full Port or Standard Port

- Outside Screw and Yoke(OS&Y)

- Bolted Bonnet with spiral-would gasket, threaded and seal welded bonnet and threaded

and pressure seal bonnet

- Backseat

- Solid or Flexible Wedge

- Butt Weld Ends to ASME B16.25

- Flanged Ends to ASME B16.5 and B16.47



Main Part & Materials:



Part Names Part Materials
Body WCB LCB WC6 CF8 CF8M CF3 CF3M C83600/C95800
Bonnet WCB LCB WC6 CF8 CF8M CF3 CF3M C83600/C95800
Disc/Ball/Wedge WCB LCB WC6 CF8 CF8M CF3 CF3M C83600/C95800
Stem F6a F304 F6a F304 F316 F304L F316L C83600/C95800
Seat/Seat Ring 13%Cr SS304 13%Cr SS304 SS316 SS304L SS316L C83600/C95800
Packing Graphite/PTFE
Gasket SS304+Graphite/SS304+Graphite
Bolts/Nuts B7/2H L7/4 B16/4 B8/8 B8M/8M B8/8 B8M/8M B8M/8M
Suitable Medium W.O.G etc. HNO3, CH3OOH etc. Sea Water etc.
Suitable Temperature -29~425 °C -46~340 °C -46~340 °C -196~427 °C -196~427 °C
