Forged Steel Cryogenic Valve
Forged Steel Cryogenic Valve
- Availability: In Stock
- Product Model: DZ61H
$0.00
Ex Tax: $0.00
Forged Steel Cryogenic Gate Valve
Technical Data:
1)Material:A105, LF2, SS304, SS316, SS304L, SS316L, F11, F22
2)Size rating:NPS 3/8"~2"
3)Working Pressure:Class150Lb~800Lb
4)Design Standard:API 602
6)Weld End: As per ASME B 16.11
7)Test Standard:API598
Material List:
| NO. | Part Name | AS to ASTM | SS to ASTM | ||
| Type LF2 | Type LF3 | Type F304(L) | Type F316(L) | ||
| 1 | Body | A350 LF2 | A350 LF3 | A182 F304(L) | A182 F316(L) |
| 2 | Seat Ring | A276 420 | A276 410 | A276 304(L) | A276 316(L) |
| 3 | Wedge | A350 LF2 | A350 LF3 | A182 F304(L) | A182 F316(L) |
| 4 | Gasket | Corrugated SS + graphite | SS + PTFE | ||
| 5 | Bonnet | A350 LF2 | A350 LF3 | A182 F304(L) | A182 F316(L) |
| 6 | Bonnet Bolt | A193 B7 | A193 B7 | A193 B8 | A193 B8M |
| 7 | Stem | A182 F6 | A182 F6 | A182 F304(L) | A182 F316(L) |
| 8 | Stem Packing | Flexible Graphite | PTFE | ||
| 9 | Pin | A276 420 | A276 304 | ||
| 10 | Gland Eyebolt | A193 B7 | A193 B16 | A193 B8 | A193 B8M |
| 11 | Gland | A276 410 | A182 F304(L) | A182 F316(L) | |
| 12 | Gland Flange | A105 | A182 F11 | A182 F304(L) | A182 F316(L) |
| 13 | Gland Nut | A194 2H | A194 4 | A194 8 | A194 8M |
| 14 | Yoke Nut | A276 420 | |||
| 15 | Bearing Gasket | A473 431 | |||
| 16 | Nameplate | SS | |||
| 17 | H.W.Lock Nut | A194 2H | A194 4 | A194 8 | A194 8M |
| 18 | Handwheel | A197 | |||
| Suitable Temperature | 40 | 101 | 196 | ||
