Double Eccentric Butterfly Valve

Double Eccentric Butterfly Valve, Double Offset Butterfly Valve

APPLICATION
Regulating and Control, bi-directional bubble tight

FEATURES / BENEFITS
Double eccentric / offset design for tight shut-off, reduced seat wear and reduced torque peak.
Spherical seat contacts the seat smoothly
Combination of seat and disc materials suitable for up to 600°C
Firesafe
Blow Out Proof Steam - Outside the pressure boundary

ANSI CLASS RATING
Class 150, 300

DESIGN STANDARD
AP 609

SIZES
50mm (2") to 600mm (24")

MATERIALS
Body: WCB, CF8, CF8M, CF3, CF3M, CD4MCu, CN7M, etc

ENDS
Wafer
Lugged
