API Forged Steel Check Vavle
API Forged Steel Check Vavle
- Availability: In Stock
- Product Model: H15Y,H65Y
$0.00
Ex Tax: $0.00
API Forged Steel Check Valve
Technical Data:
1)Material:A105, LF2, SS304, SS316, SS304L, SS316L, F11, F22
2)Size rating:NPS 1/2"~2"
3)Working Pressure:Class 800Lb~2500Lb
4)Design Standard:API 602
5)Weld End: As per ASME B 16.34
6)Test Standard:API598
Material List:
| NO. | Part Name | CStoASTM | AStoASTM | SStoASTM | |
| A105 | F22 | F304(L) | F316(L) | ||
| 1 | Body | A105 | A182F22 | A182F304(L) | A182F316(L) |
| 2 | Disc | A276420 | A276304 | A276 304(L) | A276316(L) |
| 3 | Bonnet | A105 | A182F22 | A182F304(L) | A182F316(L) |
| 4 | Nameplate | SS | |||
| Suitable Medium | W.O.G.etc | W.O.G.etc | HNO3,CH3OOH etc | ||
| Suitable Temperature | -29~425 | -29~550 | -29~180 | ||
Dimensions & Weight
| NPS | R.B. | 3/8” | 1/2” | 3/4” | 1” | 11/4” | 11/2” | 2” | |
| F.B. | 3/8” | 1/2” | 3/4” | 1” | 11/4” | 11/2” | 2” | ||
| L | 98 | 98 | 110 | 120 | 140 | 140 | 170 | 200 | |
| H（Open） | 85 | 85 | 95 | 105 | 114 | 114 | 132 | 145 | |
| Weight | 3.1 | 3 | 3.7 | 6.5 | 8.5 | 8 | 10.9 | 12.5 | |
