EPDM NR Sleeve Slurry Pinch Valve Powder Coating For Abrasive And Corrosive Liquid

EPDM NR Sleeve Slurry Pinch Valve Powder Coating For Abrasive And Corrosive Liquid
EPDM NR Sleeve Slurry Pinch Valve Powder Coating For Abrasive And Corrosive Liquid
  • Availability: In Stock
  • Product Model: GJ41X
0 Write a review
$0.00
Ex Tax: $0.00
Add to Cart
Product Inquiry
Add to Wish List Compare this Product

EPDM NR Sleeve Slurry Pinch Valve Powder Coating For Abrasive And Corrosive Liquid



Specifications



Size Range 1" (25mm) to 8" (200mm)
Temperature -10 to 120 degree C
Max. Working Pressure Up to 60psi (4bar)
Standard Face-to-Face Mill Standard
Flange Drilling ANSI 150#, DIN, JIS, AS
Actuation Plant Air
Tube Material NR, PGR, EPDM, NBR, IIR, CR, FPM, CSM
In-Line Tube Change Yes
Body Type Sealed
Body Material aluminum





Working Principle


The upper and bottom disc are moving toward each other to closed the sleeve when rotating the handwheel. Because the rubber sleeve can not bear too much strength, the valve reach closing position when the disc is contacted. No need to close the valve too tight.





Structure

The valve consists of body, sleeve, disc, guide pin and other parts.



Techinical Data



Nominal Diameter Nominal Pressure Suitable Temperature Suitable Medium
DN25~200 4 bar Natural Rubber:≤80 ℃ Ore Pulp, Grinding Material, Wet & Dry Dust
EPDM Rubber:≤120 ℃
