SS Pinch Bar Sleeve Slurry Pinch Valve Two Way Full Bore

SS Pinch Bar Sleeve Slurry Pinch Valve Two Way Full Bore
SS Pinch Bar Sleeve Slurry Pinch Valve Two Way Full Bore
  • Availability: In Stock
  • Product Model: GJ41X-10
0 Write a review
$0.00
Ex Tax: $0.00
Add to Cart
Product Inquiry
Add to Wish List Compare this Product

Two Way Full Bore SS Pinch Bar Sensomate Sleeve Slurry Pinch Valve



Description



TEKO electric actuated pinch valve is ideal control valve engineered with the highest quality standards. It is made specially for slurry of high pressure, abrasion, corrosion and aggressive. Our pinch valve offers substantial savings through improved performance, long service lifetime and low maintenance costs with pressure capabilities up to 10 bar.



Main Features



• Small, compact design
• Hygienic and easy to clean (replace tubes)
• Can handle whole blood and particulate matter
• Unobstructed flow path
• Wide variety of easily replaceable tubing sizes and
materials available
• 100% tested



Valve Sleeve Options

  • Natural Rubber
  • Nitrile Rubber
  • Neoprene
  • So on

General features and ranges for Pinch Valves



Diameter ranges From 15mm to 1000mm.
Connection to the pipe Bead end, Flange, Screwed, Slip-on, Socket.
Sleeve material Chlorobutyl (CIIR), EPDM, Hypalon® (CSM), Natural rubber (NR), Neoprene (CR), Nitrile (NBR), Polyurethane (PU), SBRT, Viton (FPM)
Temperature range From -50ºc up to +160ºC - (Depending on material).
Pressure range From -1 up to 25 bar - (Depending on material).
