Forged Steel API6D Structure Fully Welded Ball Valve Thread End With Manual Operation

Forged Steel API6D Structure Fully Welded Ball Valve Thread End With Manual Operation
Forged Steel API6D Structure Fully Welded Ball Valve Thread End With Manual Operation
Forged Steel API6D Structure Fully Welded Ball Valve Thread End With Manual Operation
Forged Steel API6D Structure Fully Welded Ball Valve Thread End With Manual Operation
Forged Steel API6D Structure Fully Welded Ball Valve Thread End With Manual Operation
  • Availability: In Stock
  • Product Model: QA61F
0 Write a review
$0.00
Ex Tax: $0.00
Add to Cart
Product Inquiry
Add to Wish List Compare this Product

A 105 Forged Steel API6D Structure Fully Welded Ball valve With Manual Operation



Description



Advantaged: Fully welded body can be buried underground directly, and has a service life as long as 30 years, so it is widely applied in natural gas long distance and buried pipelines with serious corrosion contain such as gases hydrogen sulfide.



Specifications



Specification Details
Design Standard API 6D, BS 5351
Pressure/Temperature Chart ASME B16.34, BS 5351
Face to face Dimension ASME B16.10 , API 6D
Fire Safety API 607, API 6FA
Testing Standard API 598
Flange Details ASME B16.5 up to 24″
ASME B16.47 26″ and Above
Butt-Weld End Details ASME B16.25
Size Range 2″ – 48″ (DN50 – DN1200)
ASME Class 150#, 300#, 600#, 900#, 1500#, 2500#
Bore Type Full Bore, Reduced Bore
Emergency grease Injection Device Soft Sealing
Materials

Plate or Pipe steel: A3/20#/SS304/TP304/SS316/TP316,

Forged Steel: A105 / LF2 / LF3 / F316 / F304 /F316L / F51 / F55 / F6a /

Casting Steel: WCB / LCB /LCC / CF8M / CF8 / CF3M / 4A / 6A / Inconel
Ball&Stem F6a / F316 / F304 / F316L / F51 / F55 / Inconel
Seats Soft Sealing or Metal to Metal
Operation Lever, Gearbox, Pneumatic Actuator, Electric Actuator





Main features of the Fuly Welde Ball valves are:

  • trunnion mounted ball
  • bubble thightness with valve on closed position
  • low pressure drop
  • possible installation on both flow directions
  • high reliability
  • construction according to standard ASTM - ASME - NACE - API -ANSI
  • Pressure classes: 150 - 300 - 400 - 600 - 900 - 1500
  • Dimension: 2''to 36"
  • Full bore and reduced bore
  • Connection: RF - RJ - BW



Applications



Isolating valve for maintenance-free above- and below-ground instalations in pipelines, on compressor stations and platforms.

Min. temperature range -60°C to +50°C
Standard temperature range -29°C to +50°C
Max. temperature range -29°C to +160°C
