JIS Standard BS5351 Stainless Steel Flexible Wedge Gate Valve 10K 20K
JIS Standard BS5351 Stainless Steel Flexible Wedge Gate Valve 10K 20K
- Availability: In Stock
- Product Model: Z41Y
$0.00
Ex Tax: $0.00
JIS Standard BS5351 Stainless Steel Flexible Wedge Gate Valve 10K 20K
Technical Data of JIS Ball Valve:
1) Size rating: 1/2”~24”
2) Working Pressure:10K, 20K
3) Design Standard:BS 5351
4) Flange Drilling:JIS B1212, B2214
5) Test Standard:JIS B 2003
Material List:
|
NO. |
Part Name |
Material |
||
|
1 |
Body |
A216 WCB |
SCS13 |
SCS14 |
|
2 |
Nuts |
A194 2H |
A194-8 |
A194-8 |
|
3 |
Bolts |
A193 2B |
A193-B8 |
A193-B8 |
|
4 |
Gasket |
PTFE |
PTFE |
PTFE |
|
5 |
Thrust Washer |
PTFE |
PTFE |
PTFE |
|
6 |
Packing |
PTFE |
PTFE |
PTFE |
|
7 |
Stem |
A182-F305 |
304SS |
316SS |
|
8 |
Lock piece |
A36 |
304SS |
316SS |
|
9 |
Gland Bush |
A216-WCB |
SCS13 |
SCS14 |
|
10 |
Ball |
A182-F304 |
304SS |
316SS |
|
11 |
Seat |
PTFE |
PTFE |
PTFE |
|
12 |
Cover |
A216 WCB |
SCS13 |
SCS14 |
|
13 |
Lever |
WCB |
WCB |
WCB |
