304 Stainless Steel Forged Steel Check Valve
304 Stainless Steel Forged Steel Check Valve
- Availability: In Stock
- Product Model: H61H
$0.00
Ex Tax: $0.00
304 Stainless Steel Forged Steel Check Valve
Technical Data:
1)Material:A105, LF2, SS304, SS316, SS304L, SS316L, F11, F22
2)Size rating:NPS 1/2"~2"
3)Working Pressure:Class 800Lb~2500Lb
4)Design Standard:API 602
5)Weld End: As per ASME B 16.11
6)Test Standard:API598
Material List:
| NO. | Part Name | CSTOASTM | ASTOASTM | SSTOASTM | |
| A105 | F22 | F304(L) | F316(L) | ||
| 1 | Seat | A276410 | A276304 | A276304(L) | A276316(L) |
| 2 | Pin | A276420 | A182F304 | A182F316 | |
| 3 | Seal Ring | A276304L | A276316L | ||
| 4 | Seal Nut | A105 | A182F304 | A182F304(L) | A182F316(L) |
| 5 | Body | A105 | A182F22 | A182F304(L) | A182F316(L) |
| 6 | Bonnet | A105 | A182F22 | A182F304(L) | A182F316(L) |
| 7 | Acceding Nut | A1942H | A1944 | A1948 | A1948M |
| 8 | Segment Ring | A276420 | A182F304 | A182F316 | |
| 9 | Suspensor | A193B7 | A193B16 | A193B8 | A193B8M |
| 10 | Hinge | A105 | A182F22 | A182F304(L) | A182F316(L) |
| 11 | Disc | A276410 | F304 | A182F304(L) | F316(L) |
| 12 | Nut | A1942H | A1944 | A1948 | A1948M |
| Suitable Medium | W.O.G.etc | W.O.G.etc | HNO3,CH3OOH etc | ||
| Suitable Temperature | -29~425 | -29~550 | -29~180 | ||
Dimensions
| NPS | 1/2" | 3/4" | 1" | 1-1/4" | 1-1/2" | 2" | |
| L | 900~1500Lb | 140 | 140 | 140 | 178 | 178 | 216 |
| 2500Lb | 186 | 186 | 186 | 232 | 232 | 279 | |
| H | 117 | 117 | 117 | 152 | 152 | 195 | |
| Weights | 900~1500Lb | 8.2 | 7.8 | 7.7 | 19.8 | 19.2 | 21.3 |
| 2500Lb | 10 | 9.6 | 9.4 | 21.5 | 21.1 | 22.8 | |
