Product Code: Q41F-600/900Lb
Availability: In Stock
Product Inquiry
More details

Floating Ball Valve, 2-PC Structure

Specifications:

1)Material:ASTM A105, F304L, F316L
2)Size rating:NPS 2"-3"
3)Working Pressure:CLASS 600~900 LB
4)Design Standard:API608/BS5351/API 6D
5)Face To Face Standard:ASME B16.10
6)End Connection Standard:ASME B16.5, ASME B16.47, ASME B16.25
7)Test Standard:API 598
8)Fire Safe, Anti-static and Blow-out Proof Stem
9)Full Port or Regular Port

Material List of 2PC Ball Valve:


No. Parts Name Material
1 Body ASTM A105
2 Gasket PTFE
3 Seat R-PTFE
4 Ball SS 304
5 Steel Ball SS 304
6 Anti-Static Spring SS 304
7 Stem ASTM A182 F6a
8 Gasket PTFE
9 Packing PTFE
10 Plate AISI 1045
11 Nut ASTTM A193 Gr.B7
12 Nut ASTM A194 Gr.2H
13 Lever ASTM A216 Gr.WCB
14 Gauge Blcok AISI 1010Zinc-coated
15 Bushing Gasket AISI 1045
16 Nut ASTM A194 Gr.2H
17 Gland SS 304
18 Gland Bushing ASTMA276 410
19 Bonnet ASTM A105
20 Stud ASTM A194 Gr.2H
21 Nut ASTTM A193 Gr.B7
